MAST ATP serie sewage submersible pumps are powerful, robust and yet lightweight pumps for fire brigades, technical relief organizations and municipalities (up to 2,500 l/min, up to 2.0 bar).
| Size | XS | S | M | L |
|---|---|---|---|---|
| Euro | 32/34 | 36 | 38 | 40 |
| USA | 0/2 | 4 | 6 | 8 |
| Bust(in) | 31-32 | 33 | 34 | 36 |
| Bust(cm) | 80.5-82.5 | 84.5 | 87 | 92 |
| Waist(in) | 24-25 | 26 | 27 | 29 |
| Waist(cm) | 62.5-64.5 | 66.5 | 69 | 74 |
| Hips(in) | 34-35 | 36 | 37 | 39 |
| Hips(cm) | 87.5-89.5 | 91.5 | 94 | 99 |
With your arms relaxed at your sides, measure around the fullest part of your chest.
Measure around the narrowest part of your natural waist, generally around the belly button. To ensure a comfortable fit, keep one finger between the measuring tape and your body.
Tough: made for rough work
The non-clogging channel impeller is made of particularly impact-resistant special cast iron in accordance with DIN 1561, so that long-fibrous solids with a high density can also be conveyed. Since the impeller has a grain passage of up to 80 mm, no protective screen is required.
Maintenance-free: For constant operational readiness
Oil filling, lubricating points, use of sealing compounds, adjustment work: none of this is necessary, the pump is always ready for use. A special mechanical seal makes the pump reliably safe to run dry.
Robust: defies the toughest conditions
The pump and drive motors have already proven their high reliability and robustness thousands of times. As a further development of the robust MAST construction pumps, our transfer pumps defy the toughest conditions.
Resistant: uncompromising material quality
The motor housing and all housing parts that are subject to heavy loads in use are robust cast parts made of seawater-resistant aluminum alloy according to DIN EN 1706. The seals are of oil-resistant NBR quality, the screws are made of stainless steel. The pumping of mineral oil/water mixtures is also possible without any problems.
Features:
- Weight: 27 kg
- Size: 44 × 26 × 43 cm
- Motor: 230 V
- Power P1: 1,8 kW
- Nominal current: 8,4 A
- Head H (max.): 11 m
- Flow rate Q (max.): 1,100 l/min
- Connection thread: G 3″ / G2,5″ (suction/pressure)
- Storz coupling: 75-B
- Free passage of hard particles: up to 65 mm
- Connection cable: H 07 RN-F 3G 1.5 (20 m)
- Connection plug: Safety plug 16A IP67 (blue) according to DIN VDE 0620
