The Reveal ShieldPRO is one of the most advanced and compact thermal imaging cameras available. Robust, durable, and easy to use, the Reveal ShieldPRO combines powerful hardware with an intuitive design. The thermal sensor, with a resolution of 320 x 240 pixels and a 15 Hz frame rate, delivers a clear, informative image. Fight fires smarter and safer.
| Size | XS | S | M | L |
|---|---|---|---|---|
| Euro | 32/34 | 36 | 38 | 40 |
| USA | 0/2 | 4 | 6 | 8 |
| Bust(in) | 31-32 | 33 | 34 | 36 |
| Bust(cm) | 80.5-82.5 | 84.5 | 87 | 92 |
| Waist(in) | 24-25 | 26 | 27 | 29 |
| Waist(cm) | 62.5-64.5 | 66.5 | 69 | 74 |
| Hips(in) | 34-35 | 36 | 37 | 39 |
| Hips(cm) | 87.5-89.5 | 91.5 | 94 | 99 |
With your arms relaxed at your sides, measure around the fullest part of your chest.
Measure around the narrowest part of your natural waist, generally around the belly button. To ensure a comfortable fit, keep one finger between the measuring tape and your body.
The Reveal ShieldPRO is one of the most advanced and compact thermal imaging cameras available. Robust, durable, and easy to use, the Reveal ShieldPRO combines powerful hardware with an intuitive design. The thermal sensor, with a resolution of 320 x 240 pixels and a 15 Hz frame rate, delivers a clear, informative image. Fight fires smarter and safer. Light is available at the touch of a button: the internal LED provides 300 lumens of illumination, enough for good visibility at the scene.
The Reveal ShieldPRO delivers high-resolution thermal imaging at an unbeatable price-performance ratio. Fire sources, smoldering fires, heat sources, and missing persons can be easily located, even in complete darkness or heavy smoke.
In addition to its classic use by firefighters for firefighting, this device is also of interest to security forces and police. For example, cars and trucks can be checked for heat signatures (brakes, tires, cargo area, temperature during the transport of hazardous materials, etc.).
A large stainless steel D-ring is attached to the camera as standard for securing it to your gear. Useful accessories for the camera, such as a GearKeeper retractor or a practical holster for protection, are also available.
Features:
- Ideal for tactical operations and search and rescue
- Three selectable image modes (Color, Survey, Night Vision)
- 4 GB internal memory for up to 4,000 photos
- Integrated LED flashlight
- High image resolution and frame rate for clear, informative images
- Robust two-component housing for a secure grip
- Can be charged with a standard micro-USB cable
- Dimmable screen for covert night operations
- 4x digital zoom
Technical Specifications:
- Sensor image resolution: 320 x 240 pixels
- Frame rate: >15 Hz
- Display size: 2.4"
- Power-on time: 8 seconds
- Protection class: IP67
- Operating time: approx. 3.5 hours
- Charging time: approx. 1.5 hours
- Detection range: 758 m
- Operating temperature: -20° to +60°C
- Battery: Li-ion 3.7 V 1,650 mAh
- Weight: 180 g
- Dimensions: 127 x 61 x 31 mm
Scope of delivery:
- Thermal imaging camera
