GAS DETECTOR INDSCI TANGO TX1 - NO2

- DualSense® Technology increases worker safety by using two sensors to detect the same gas
- Guaranteed for Life™ with replaceable sensors and batteries that extends the life of the instrument
- Optional AlarmAmp™ increases audible alarms to 110 dB
- Acknowledgeable gas alerts

INSTRUMENT WARRANTY
Guaranteed for Life™. Warranted for as long as the instrument is supported by Industrial Scientific Corporation (excludes sensors, batteries, and filters). CO and H2S sensors are warranted for three years. All other sensors are warranted for two years.

DISPLAY
- Segment liquid crystal display (LCD)

KEYPAD
- Two buttons

CASE MATERIALS
- Case top: Polycarbonate with a protective rubber overmold
- Case bottom: Conductive polycarbonate

ALARMS
- Three strobe-emitting visual alarm LEDs (two red; one blue)
- 100 decibel (dB) audible alarm at a distance of 10 cm (3.94 in);
- Vibration alarm

DIMENSIONS
- 99 x 51 x 35 mm (3.9 x 2.0 x 1.4 in)

WEIGHT
- 126.0 g (4.4 oz)

TEMPERATURE RANGE
-40 °C to 50 °C  (-40 °F to 122 °F)

HUMIDITY RANGE
- 15% to 95% Non-condensing (continuous)

SENSORS
- CO, CO/H2, H2S, NO2, SO2 – Electrochemical sensor technology

SENSOR MEASURING RANGES
- Carbon Monoxide (CO): 0 to 1,000 ppm in 1 ppm increments
- Carbon Monoxide (CO/H2 low): 0 to 1,000 ppm in 1 ppm increments
- Hydrogen Sulfide (H2S): 0.0 to 500.0 ppm in 0.1 ppm increments
- Nitrogen Dioxide (NO2): 0.0 to 150.0 ppm in 0.1 ppm increments
- Sulfur Dioxide (SO2): 0.0 to 150.0 ppm in 0.1 ppm increments

BATTERY
3.6 V Primary lithium-thionyl chloride (Li-SOCl2); 1.5AH, 2/3AA; replaceable; non rechargeable; always on; up to 2-year run time depending on operating conditions

DATA LOGGING
- 3 months at 10-second intervals

EVENT LOGGING
- 60 alarm events

CERTIFICATIONS
- INGRESS PROTECTION IP66/67

-40 °C to 50 °C (-40 °F to 122 °F)
- ATEX: Ex ia I Ma; Ex ia IIC T4 Ga; Equipment Group/Category: I M1/II 1G CSA : Cl I, Gr A-D, T4; Ex ia IIC T4
- IECEx: Ex ia I Ma; Ex ia IIC T4 Ga INMETRO: Ex ia I Ma; Ex ia IIC T4 Ga
- UL (C-US): Cl I, Gr A-D, T4; Cl II, Gr E-G; Cl I, Zone 0, AEx ia IIC T4

-20 °C do 50 °C (-4 °F do 122 °F)
- China Ex: Ex ia IIC T4 Ga CMA: Ex ia I Ma; H2S, CO
- EAC: PO Ex ia I X; 0 Ex iX IIC T4 X
- KC: Ex ia IIC T4

ACCESSORIES
- DSX™ Docking Station for Tango® TX1
  A – DSX Mode: 0 = DSX Standalone, 1 = DSXi Cloud-connected, 2 = DSX-L Local Server
  B – Number of Gas Inlet Ports: 3 = 3 Ports, 6 = 6 Ports
  C – Power Cord Type: 1 = North America, 2 = Europe, 3 = Australia, 4 = UK Replacement battery
- Soft nylon case, Black
- Soft nylon case, Safety Orange
- Dust barrier kit, 5 pack
- Water barrier kit, 5 pack
- CalCup and tubing kit
- Suspender clip
- AlarmAmp, Black
- AlarmAmp, Safety Orange Black
- Nameplate: Green, Yellow, Blue, White
